Cincon Electronics Co., Ltd. je globálním dodavatelem spínaných napájecích zdrojů pro telekomunikační, počítačové, průmyslové, lékařské, spotřebitelské a osvětlovací trhy. Cincon navrhuje a vyrábí standardní DC-DC měniče, AC-DC napájecí zdroje a LED napájecí zdroje vyhovující RoHS.
Jejich současná produktová řada zahrnuje více než 3 000 standardních produktů, včetně jedno a více výstupních DC/DC měničů od 1W do 750W, jedno a více výstupních AC napájecích zdrojů od 5W do 150W, otevřených AC-DC napájecích zdrojů od 5W do 700W a LED zdroje od 15W do 150W.

Stažení


AC/DC Power Supply


Description

Datasheet

Input

Power

Size

  • CBM70S

    CBM70S

    • Univerzální vstupní rozsah 90~264V stříd.
    • Účinnost až 89,5 %
    • Plná zátěž s chlazenou základní deskou a bez ventilátoru
    • Široký rozsah provozních teplot
    90-264
    70W
    48.3 x 61 mm
  • CBM101S

    CBM101S

    • Univerzální vstupní rozsah 90~264V stříd.
    • Vysoká účinnost až 94,5 %
    • Třída I
    • Příkon bez zátěže<0,5W
    90-264
    100W
    106,7 x 61 mm
  • CBM100S

    CBM100S

    • Univerzální vstupní rozsah 90~264V stříd.
    • Plná zátěž s chlazenou základní deskou a bez ventilátoru
    • Široký rozsah provozních teplot
    • 17mm ultranízkoprofilový balíček
    90-264
    100W
    106,7 x 61 mm
  • PDF700S

    PDF700S

    • Univerzální vstupní rozsah 90~264V stříd.
    • Účinnost až 91,5 %
    • Plná velikost cihel
    • Třída I
    90-264
    700W
    106,7 x 61 mm
  • PFC750

    PFC750

    • Univerzální vstupní rozsah
    • Účinnost až 96,5 %
    • Velikost poloviční cihly
    • Bezpečnost schválení IEC/EN/UL 62368-1
    90-264
    750W
    61 x 57.9 mm
  • LFM300S-C

    LFM300S-C

    • Univerzální vstupní rozsah 85–264 VAC
    • Vysoká účinnost až 94 %
    • 25,4 mm nízkoprofilový balíček
    • Příkon při nečinnosti <0,3 W
    85~264
    300 W
    3.173x1.885x1.704
  • PDF700S-CMFC(D/D-P)

    PDF700S-CMFC(D/D-P)

    • Univerzální vstupní rozsah 90–264 VAC
    • Účinnost až 91,5 %
    • Bezpečnostní schválení IEC/EN/UL 62368-1 Ed 3.0
    • Provozní výška 5000 m
    90~264Vac
    700 W
    9,45 x 1,65 x 4,33
  • CBM150S

    CBM150S

    • Univerzální vstupní rozsah 90~264V stříd.
    • Vysoká účinnost až 93 %
    • Třída I
    • Příkon bez zátěže<0,5W
    90-264
    150 Watt
    4.2 x 0.78 x 2.40 inches
    (106.7 x 19.7 x 61 mm)
  • CSC01

    CSC01

    • Aktuální modul sdílení pro Parallel
    • Metody poklesu napětí
    • Žádný požadavek na připojení kolíku pro sdílení
    • Žádný tantalový kondenzátor uvnitř
    11 - 60 Vdc
    -
    1.25X0.80X0.50 Inches


Description

Datasheet

Input

Power

Size

  • CFM04S

    CFM04S

    • Univerzální vstupní rozsah 85~305Vac
    • Vysoká účinnost až 82 %
    • Kompaktní velikost 0,764” x 1,555”
    • Třída II
    85~305
    4W
    0.764”x 1.555”
  • CFM06S

    CFM06S

    • Altitude 5000m
    • Meets EN60335-1
    • Class II
    • Universal Input 90~264VAC
    90-264
    6 W
    1.555x0.764x0.720 (PCB-mount) 1.618x0.827x0.787 (Encapsulated) 1.950.x0.728x0.689 (Wafer)
  • CFM10

    CFM10

    • Leakage Current 0.25mA
    • Continuous Short Circuit Protection
    • Approved IEC/EN/UL62368-1
    • Universal Input 90~264VAC
    85-264
    10 W
    2.599x1.772x0.906 (PCB-mount)
  • LFM420M

    LFM420M

    • Univerzální vstupní rozsah 85~264 V AC
    • Vysoká účinnost až 94,5 %
    • Třída I
    • Balík s nízkým profilem 25,4 mm
    85~264
    420 W
    25.4mm Low Profile Package
  • LFM420S

    LFM420S

    • Univerzální vstupní rozsah 85~264 V AC
    • Vysoká účinnost až 94,5 %
    • Třída I
    • Balík s nízkým profilem 25,4 mm
    85~264
    420 W
    25.4mm Low Profile Package
  • CFM12S

    CFM12S

    • Altitude 5000m
    • Approval EN60335-1
    • Class II
    • Universal Input 90~264VAC
    90-264
    12 W
    1.500x1.000x0.764 (PCB-mount) 1.600x1.1x0.772 (Encapsulated) 2.150x1.000x0.681 (Wafer)
  • LFM300M-C

    LFM300M-C

    • Univerzální vstupní rozsah 85~264 Vac
    • Vysoká účinnost až 94 %
    • 25,4mm nízkoprofilový balíček
    • Příkon bez zátěže<0,3W
    85~264
    300 W
    4,09 x 1,00 x 2,28
  • CFM15

    CFM15

    • Leakage Current 0.25mA
    • Efficiency to 83%
    • Meets EN55032 Class B
    • Approved IEC/EN/UL62368-1
    85-264
    15 W
    2.752x1.890x0.906 (PCB-mount)
  • CFM21

    CFM21

    • 2MOOP
    • Miniature Size Low Profile 0.8”
    • Universal Input Range 90~264VAC
    • IEC/EN/UL 60601-1 Medical Safety Approved
    90-264
    20 W
    2.38x1.60x0.80 (PCB-mount) 3.00x1.60x0.77 (Wafer) 2.53x1.74x0.80 (Encapsulated) 3.00x1.60x0.77 (Screw Terminal)
  • CFM21M

    CFM21M

    • 2MOOP
    • Low Profile
    • Universal Input Range 90~264VAC
    • Altitude 5000m
    90-264
    20 W
    2.38x1.60x0.80 (PCB-mount) 3.00x1.60x0.77 (Wafer) 2.53x1.74x0.80 (Encapsulated) 3.00x1.60x0.77 (Screw Terminal)
  • CFM25S

    CFM25S

    • 2 Times Peak Load
    • Altitude 5000m
    • Approval EN60335-1
    • Class II
    90-264
    25 W
    2.000x1.100x0.980 (PCB-mount) 2.091x1.193x0.976 (Encapsulated) 2.776x1.100x0.906 (Wafer)
  • CFM36S

    CFM36S

    • Univerzální vstupní rozsah 90–264 VAC
    • Vysoká účinnost až 89 %
    • Velikost 1,5" x 3"
    • Třída II: Zadejte „Empty“ a „E“
    90-264
    36 W
    1.5”x 3” Size
  • CFM40S

    CFM40S

    • High Peak Load
    • Universal Input Range 90~264VAC
    • 2”x 4” Size
    • Industry Standard Pin Out
    90-264
    40 W
    4.000x2.000x1.275 (PCB-mount) 4.000x2.000x1.200 (Wafer) 4.606x2.441x1.575 (Cover)
  • CFM40M

    CFM40M

    • 2MOOP
    • Meets EN60335-1
    • Universal Input Range 90~264VAC
    • Medical and ITE Approved
    90-264
    40 W
    3.000x2.000x0.948 (PCB-mount) 3.000x2.000x0.909 (Wafer) 3.200x2.441x1.260 (Cover)
  • CFM41S

    CFM41S

    • 2 Times Peak Load
    • Altitude 5000m
    • Meets EN60335-1
    • Class II
    90-264
    40 W
    2.000x2.000x1.01 (PCB-mount) 2.14x2.14x1.035 (Encapsulated) 2.70x2.00x0.941 (Wafer)
  • CFM40D/T

    CFM40D/T

    • Dual & Triple Outputs
    • Universal Input Range 90~264VAC
    • Industry-Standard Pin Out
    • Meets EN61204-3 Class B and CISPR/FCC Class B
    90-264
    40 W
    4.000x2.000x1.200 (Wafer) 4.606x2.441x1.575 (Cover)
  • CFM50S

    CFM50S

    • Altitude 5000m
    • Meets EN60335-1
    • ClassⅠ& Class Ⅱ
    • 2”x 3” Open Frame Compact Size
    90-264
    50 W
    3.000x2.000x1.067 (Wafer) 3.000x2.00x1.142 (PCB Mount) 3.598x2.520x1.358 (Cover)
  • CFM61S

    CFM61S

    • 2 Times Peak Load
    • Altitude 5000m
    • Universal Input 90~264VAC
    • Class II
    90-264
    60 W
    2.000x2.000x1.346 (PCB-mount) 2.136x2.136x1.409 (Encapsulated) 2.700x2.000x1.291 (Wafer)
  • CFM60M

    CFM60M

    • 2MOOP
    • 2”x 4” Size
    • Universal Input Range 90~264VAC
    • Efficiency to 90%
    90-264
    60 W
    4.000x2.000x1.100 (Wafer) 4.606x2.441x1.575 (Cover)
  • CFM60T

    CFM60T

    • Triple Outputs
    • Universal Input Range 90~264VAC
    • Industry-Standard Pin Out
    • Meets EN61204-3 Class B and CISPR/FCC Class B
    90-264
    60 W
    4.000x2.000x1.260 (Wafer)
  • CFM60S

    CFM60S

    • High Peak Load
    • Universal Input Range 90~264VAC
    • Industry-Standard Pin Out
    • Meets EN61204-3 Class B and CISPR/FCC Class B
    90-264
    60 W
    4.000x2.000x1.275 (PCB-mount) 4.000x2.000x1.200 (Wafer) 4.606x2.441x1.575 (Cover)
  • CFM70S

    CFM70S

    • Altitude 5000m
    • Universal Input Range 90~264VAC
    • Meets EN60335-1
    • ClassⅠ& Class Ⅱ
    90-264
    70 W
    3.000x2.000x1.067 (Wafer) 3.000x2.00x1.142 (PCB Mount) 3.598x2.520x1.358 (Cover)
  • CFM81S

    CFM81S

    • 2 Times Peak Load
    • Altitude 5000m
    • Approval EN60335-1
    • ClassⅠ& Class Ⅱ
    90-264
    80 W
    3.000x2.000x1.339 (Wafer) 3.200x2.441x1.575 (Cover)
  • CFM80S

    CFM80S

    • EN61000-3-2 Class A
    • Meet EN55032 Class B
    • Meet CISPR / FCC Class B
    • Short Circuit Protection
    90-264
    80 W
    4.000x2.000x1.142 (PCB-mount) 4.000x2.000x1.07 (Wafer)
  • CFM100M

    CFM100M

    • 2MOOP
    • 3”x 5” Compact Size
    • Less than 1 U high
    • High Efficiency up to 92%
    90-264
    100 W
    5.000x3.000x1.050 (Wafer)
  • CFM130M

    CFM130M

    • 2MOOP
    • Altitude 5000m
    • Meets EN60335-1
    • Class I & Class II
    80-264
    130 W
    3.000x2.000x1.20 (Open-frame) 3.598x2.000x1.299 (Baseplate) 3.598x2.520x1.358 (Cover)
  • CFM130S

    CFM130S

    • Universal Input Range 80~264Vac
    • Meets EN60335-1
    • Class Ⅰ & Class Ⅱ
    • Short Circuit Protection
    80-264
    130 W
    3.000x2.000x1.20 (Open-frame) 3.598x2.000x1.299 (Baseplate) 3.598x2.520x1.358 (Cover)
  • CFM150M

    CFM150M

    • 2MOOP
    • Universal Input Range 90 ~ 264Vac
    • 3”x 5” Compact Size
    • Less than 1 U High：1.05”
    90-264
    150 W
    5.000x3.000x1.050 (Wafer)
  • CFM150S

    CFM150S

    • Universal Input Range 80~264Vac
    • Meets EN60335-1
    • Class Ⅰ & Class Ⅱ
    • High Efficiency up to 94%
    90-264
    150 W
    4.00x2.00x1.283 (Open-frame) 4.598x2.00x1.362 (Baseplate)
  • LFM200S

    LFM200S

    • Univerzální vstupní rozsah 85~264 V AC
    • Třída I
    • Balík s nízkým profilem 25,4 mm
    • Příkon bez zátěže<0,3W
    85~264
    200 W
    3.09x2.28x1.00 Inches (78.6x57.9x25.4 mm)
  • CFM202S

    CFM202S

    • Universal Input Range 90~264Vac
    • High Efficiency up to 94%
    • 2”x 4” Open Frame Compact Size
    • Open Frame Baseplate-cooled Power Supply
    90~264
    200 W
    4.000x2.000x1.311 (Baseplate) 4.598x2.520x1.358 (Cover)
  • CFM260S

    CFM260S

    • Universal Input Range 80~264Vac
    • Meets EN60335-1
    • Class I
    • High Efficiency up to 93.5% Typical
    85-264
    260 W
    4.000x2.000x1.441 (Open-frame) 4.598x2.000x1.520 (Baseplate) 4.598x2.520x1.594 (Cover)
  • CFM300M

    CFM300M

    • 2MOOP
    • High Efficiency up to 94%
    • High Power Density up to 14.1W/Inch3
    • Class I
    90-264
    300 W
    5.000x3.000x1.421 (Baseplate) 5.355x3.425x1.591 (Cover)
  • CFM300S

    CFM300S

    • Universal Input Range 80~264Vac
    • Altitude 5000m
    • Meets EN60335-1
    • Class I
    90-264
    300 W
    5.000x3.000x1.421 (Baseplate) 5.355x3.425x1.591 (Cover)
  • CFM351M

    CFM351M

    • 2MOOP
    • Universal Input Range 90 ~ 264Vac
    • Meets EN60601-1 and EN55011 Class B
    • Active PFC Meets EN61000-3-2 Class D
    90-264
    350 W
    6.500x4.000x1.516 (Wafer)
  • CFM400S Series

    CFM400S Series

    • Univerzální vstupní rozsah 80~264 Vac
    • Vysoká účinnost až 94 %
    • Kompaktní velikost 3” x 5”
    • Třída I
    80~264
    400 W
    3”x 5” Compact Size
  • CFM500S-PM

    CFM500S-PM

    • Univerzální vstupní rozsah 80~264V stříd.
    • nadmořská výška 5000 m
    • Splňuje normu EN60335-1
    • Vysoká účinnost až 94,5 %
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)
  • CFM500S

    CFM500S

    • Universal Input Range 80~264Vac
    • Altitude 5000m
    • Meets EN60335-1
    • High Efficiency up to 94.5%
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)
  • CFM500M

    CFM500M

    • 2MOOP
    • Altitude 5000m
    • Meets EN60335-1
    • Class I
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)


Description

Datasheet

Input

Power

Size

  • CFM21

    CFM21

    • 2MOOP
    • Miniature Size Low Profile 0.8”
    • Universal Input Range 90~264VAC
    • IEC/EN/UL 60601-1 Medical Safety Approved
    90-264
    20 W
    2.38x1.60x0.80 (PCB-mount) 3.00x1.60x0.77 (Wafer) 2.53x1.74x0.80 (Encapsulated) 3.00x1.60x0.77 (Screw Terminal)
  • CFM40C

    CFM40C

    • EN55032 Class B
    • Short Circuit Protection
    • Over Voltage Protection
    • Efficiency 90%
    90-264
    40 W
    5.433x2.323x1.894
  • CFM40M

    CFM40M

    • 2MOOP
    • Meets EN60335-1
    • Universal Input Range 90~264VAC
    • Medical and ITE Approved
    90-264
    40 W
    3.000x2.000x0.948 (PCB-mount) 3.000x2.000x0.909 (Wafer) 3.200x2.441x1.260 (Cover)
  • CFM40S

    CFM40S

    • High Peak Load
    • Universal Input Range 90~264VAC
    • 2”x 4” Size
    • Industry Standard Pin Out
    90-264
    40 W
    4.000x2.000x1.275 (PCB-mount) 4.000x2.000x1.200 (Wafer) 4.606x2.441x1.575 (Cover)
  • CFM40D/T

    CFM40D/T

    • Dual & Triple Outputs
    • Universal Input Range 90~264VAC
    • Industry-Standard Pin Out
    • Meets EN61204-3 Class B and CISPR/FCC Class B
    90-264
    40 W
    4.000x2.000x1.200 (Wafer) 4.606x2.441x1.575 (Cover)
  • CFM60C

    CFM60C

    • EN55032 Class B
    • Short Circuit Protection
    • Over Voltage Protection
    • Efficiency 90%
    90-264
    60 W
    5.433x2.323x1.894
  • CFM60M

    CFM60M

    • 2MOOP
    • 2”x 4” Size
    • Universal Input Range 90~264VAC
    • Efficiency to 90%
    90-264
    60 W
    4.000x2.000x1.100 (Wafer) 4.606x2.441x1.575 (Cover)
  • CFM60S

    CFM60S

    • High Peak Load
    • Universal Input Range 90~264VAC
    • Industry-Standard Pin Out
    • Meets EN61204-3 Class B and CISPR/FCC Class B
    90-264
    60 W
    4.000x2.000x1.275 (PCB-mount) 4.000x2.000x1.200 (Wafer) 4.606x2.441x1.575 (Cover)
  • CFM81S

    CFM81S

    • 2 Times Peak Load
    • Altitude 5000m
    • Approval EN60335-1
    • ClassⅠ& Class Ⅱ
    90-264
    80 W
    3.000x2.000x1.339 (Wafer) 3.200x2.441x1.575 (Cover)
  • CFM130M

    CFM130M

    • 2MOOP
    • Altitude 5000m
    • Meets EN60335-1
    • Class I & Class II
    80-264
    130 W
    3.000x2.000x1.20 (Open-frame) 3.598x2.000x1.299 (Baseplate) 3.598x2.520x1.358 (Cover)
  • CFM130S

    CFM130S

    • Universal Input Range 80~264Vac
    • Meets EN60335-1
    • Class Ⅰ & Class Ⅱ
    • Short Circuit Protection
    80-264
    130 W
    3.000x2.000x1.20 (Open-frame) 3.598x2.000x1.299 (Baseplate) 3.598x2.520x1.358 (Cover)
  • CFM260S

    CFM260S

    • Universal Input Range 80~264Vac
    • Meets EN60335-1
    • Class I
    • High Efficiency up to 93.5% Typical
    85-264
    260 W
    4.000x2.000x1.441 (Open-frame) 4.598x2.000x1.520 (Baseplate) 4.598x2.520x1.594 (Cover)
  • CFM300M

    CFM300M

    • 2MOOP
    • High Efficiency up to 94%
    • High Power Density up to 14.1W/Inch3
    • Class I
    90-264
    300 W
    5.000x3.000x1.421 (Baseplate) 5.355x3.425x1.591 (Cover)
  • CFM300S

    CFM300S

    • Universal Input Range 80~264Vac
    • Altitude 5000m
    • Meets EN60335-1
    • Class I
    90-264
    300 W
    5.000x3.000x1.421 (Baseplate) 5.355x3.425x1.591 (Cover)
  • CFM500M

    CFM500M

    • 2MOOP
    • Altitude 5000m
    • Meets EN60335-1
    • Class I
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)
  • CFM500S

    CFM500S

    • Universal Input Range 80~264Vac
    • Altitude 5000m
    • Meets EN60335-1
    • High Efficiency up to 94.5%
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)
  • CFM500S-PM

    CFM500S-PM

    • Univerzální vstupní rozsah 80~264V stříd.
    • nadmořská výška 5000 m
    • Splňuje normu EN60335-1
    • Vysoká účinnost až 94,5 %
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)


Description

Datasheet

Input

Power

Size

  • TRE06

    TRE06

    • Universal Input Range 90~264Vac
    • High Efficiency up to 81%
    • Miniature Size
    • Optional US&EU AC Plugs
    90-264
    6 W
    2.047x1.417x0.992
  • TRG10R

    TRG10R

    • Level VI Efficiency
    • High Efficiency up to 84%
    • Interchangeable AC Plugs
    • Approved IEC/EN/UL 62368-1
    90-264
    10 W
    2.858x1.823x1.402
  • TRE15

    TRE15

    • Universal Input Range 90~264Vac
    • Altitude 5000m
    • High Efficiency up to 86%
    • No Load Power Consumption < 75mW
    90-264
    15 W
    2.795x1.906x1.299
  • TRG15

    TRG15

    • Universal Input Range 90~264Vac
    • High Efficiency up to 86%
    • Approved IEC/EN/UL 62368-1
    • No Load Power Consumption < 75mW
    90-264
    15 W
    2.835x2.047x1.378
  • TRE15R

    TRE15R

    • Cost Effective
    • High Efficiency up to 86%
    • Interchangeable AC Plugs
    • Altitude 5000m
    90-264
    15 W
    2.795x2.220x1.299
  • TRE15RD

    TRE15RD

    • Cost Effective
    • High Efficiency up to 86%
    • Interchangeable AC Plugs
    • Altitude 5000m
    90-264
    15 W
    2.835x2.244x1.299
  • TR15RAM

    TR15RAM

    • 2 MOPP
    • Universal Input Range 90~264Vac
    • High Efficiency up to 82%
    • Class II
    90-264
    15 W
    3.173x1.885x1.704
  • TR18RDM

    TR18RDM

    • 2 MOPP
    • Altitude 5000m
    • EN60601-1-11 IP22
    • Meets EN60335-1
    80-264
    18 W
    3.165x1.693x1.453
  • TRE25

    TRE25

    • Universal Input Range 90~264Vac
    • High Efficiency up to 88%
    • Class II
    • Cost Effective
    90-264
    25 W
    2.795x1.906x1.299
  • TRE25R

    TRE25R

    • Cost Effective
    • High Efficiency up to 88%
    • Interchangeable AC Plugs
    • Class II
    90-264
    25 W
    2.795x2.220x1.299
  • TR30RDM

    TR30RDM

    • 2 MOPP
    • Altitude 5000m
    • EN60601-1-11 IP22
    • Meets EN60335-1
    80-264
    30 W
    3.807x2.283x1.703
  • TR30RAM

    TR30RAM

    • 2 MOPP
    • Universal Input Range 90~264Vac
    • High Efficiency up to 87%
    • Leakage Current < 100uA
    90-264
    30 W
    4.278x2.440x1.445
  • TRG30RAV

    TRG30RAV

    • Leakage Current < 0.25mA
    • High Efficiency up to 88%
    • Interchangeable AC Plugs
    • Approval IEC/EN/UL 62368-1
    90-264
    30 W
    4.278x2.440x1.445
  • TRG30RV

    TRG30RV

    • Leakage Current < 0.25mA
    • High Efficiency up to 88%
    • Interchangeable AC Plugs
    • Approval IEC/EN/UL 62368-1
    90-264
    30 W
    4.243x2.267x1.319
  • TRE36

    TRE36

    • Meets EN60335-1
    • Altitude 5000m
    • High Efficiency up to 89%
    • Approved IEC/EN/UL 62368-1
    90-264
    36 W
    3.937x1.771x0.886
  • TRG36A

    TRG36A

    • Level VI Efficiency
    • Universal Input Range 90~264Vac
    • High Efficiency up to 89%
    • Class II
    90-264
    36 W
    4.370x2.008x0.886
  • TR36M

    TR36M

    • 2MOPP
    • Altitude 5000m
    • EN60601-1-11 IP21
    • Meets EN60335-1
    80-264
    36 W
    3.937x1.771x0.886
  • TRH50A

    TRH50A

    • Altitude 5000m
    • Universal Input Range 90~264Vac
    • High Efficiency up to 89%
    • Class II
    90-264
    50 W
    4.724x2.047x1.220
  • TR60M

    TR60M

    • 2MOPP
    • Level V
    • High Efficiency up to 88%
    • Class II
    90-264
    60 W
    5.197x2.283x1.201
  • TRH70A

    TRH70A

    • Altitude 5000m
    • Universal Input Range 90~264Vac
    • High Efficiency up to 89%
    • Class II
    90-264
    70 W
    4.724x2.047x1.220
  • TR70M

    TR70M

    • 2MOPP
    • Altitude 5000m
    • Meets EN60335-1
    80-264
    70 W
    4.724x2.047x1.220
  • TRH100A

    TRH100A

    • Altitude 5000m
    • Universal Input Range 90~264Vac
    • High Efficiency up to 89%
    • Class II
    90-264
    100 W
    5.591x2.283x1.457
  • TR100M

    TR100M

    • 2MOPP
    • Universal Input Range 90~264Vac
    • High Efficiency up to 98%
    • Class II
    90-264
    100 W
    5.591x2.283x1.457
  • TRH160A

    TRH160A

    • Altitude 5000m
    • Universal Input Range 90~264Vac
    • High Efficiency up to 89%
    • Class II
    90-264
    160 W
    5.906x2.756x1.497
  • TR160M

    TR160M

    • 2MOPP
    • Altitude 5000m
    • Meets EN60335-1
    80-264
    160 W
    5.906x2.756x1.496
  • TR220M

    TR220M

    • 2MOPP
    • Altitude 5000m
    • High Efficiency up to 94%
    • Universal Input Range 80~264Vac
    80-264
    220 W
    7.087x2.953x1.752
  • TRH220A

    TRH220A

    • Universal Input Range 90~264Vac
    • High Efficiency up to 94%
    • Class I
    • No Load Input Power Consumption < 150mW
    90-264
    200.04W - 220.08W
    5.591x2.283x1.457


Description

Datasheet

Input

Power

Size

  • CFM06S

    CFM06S

    • Altitude 5000m
    • Meets EN60335-1
    • Class II
    • Universal Input 90~264VAC
    90-264
    6 W
    1.555x0.764x0.720 (PCB-mount) 1.618x0.827x0.787 (Encapsulated) 1.950.x0.728x0.689 (Wafer)
  • CFM12S

    CFM12S

    • Altitude 5000m
    • Approval EN60335-1
    • Class II
    • Universal Input 90~264VAC
    90-264
    12 W
    1.500x1.000x0.764 (PCB-mount) 1.600x1.1x0.772 (Encapsulated) 2.150x1.000x0.681 (Wafer)
  • CFM21M

    CFM21M

    • 2MOOP
    • Low Profile
    • Universal Input Range 90~264VAC
    • Altitude 5000m
    90-264
    20 W
    2.38x1.60x0.80 (PCB-mount) 3.00x1.60x0.77 (Wafer) 2.53x1.74x0.80 (Encapsulated) 3.00x1.60x0.77 (Screw Terminal)
  • CFM25S

    CFM25S

    • 2 Times Peak Load
    • Altitude 5000m
    • Approval EN60335-1
    • Class II
    90-264
    25 W
    2.000x1.100x0.980 (PCB-mount) 2.091x1.193x0.976 (Encapsulated) 2.776x1.100x0.906 (Wafer)
  • CFM41S

    CFM41S

    • 2 Times Peak Load
    • Altitude 5000m
    • Meets EN60335-1
    • Class II
    90-264
    40 W
    2.000x2.000x1.01 (PCB-mount) 2.14x2.14x1.035 (Encapsulated) 2.70x2.00x0.941 (Wafer)
  • CFM61S

    CFM61S

    • 2 Times Peak Load
    • Altitude 5000m
    • Universal Input 90~264VAC
    • Class II
    90-264
    60 W
    2.000x2.000x1.346 (PCB-mount) 2.136x2.136x1.409 (Encapsulated) 2.700x2.000x1.291 (Wafer)
  • CBM70S

    CBM70S

    • Low Profile
    • Wide Operating Temp.
    • Built-in EMI Filter & Capacitor
    • Class I
    90-264
    70 W
    2.28x2.40x0.67
  • PFC750

    PFC750

    • Low Profile
    • Built-in PFC
    • Altitude 5000
    90-264
    750 W
    2.28x2.40x0.50


Description

Datasheet

Input

Power

Size

  • LFM300S-C

    LFM300S-C

    • Univerzální vstupní rozsah 85–264 VAC
    • Vysoká účinnost až 94 %
    • 25,4 mm nízkoprofilový balíček
    • Příkon při nečinnosti <0,3 W
    85~264
    300 W
    3.173x1.885x1.704
  • CBM70S

    CBM70S

    • Low Profile
    • Wide Operating Temp.
    • Built-in EMI Filter & Capacitor
    • Class I
    90-264
    70 W
    2.28x2.40x0.67
  • CFM130S

    CFM130S

    • Universal Input Range 80~264Vac
    • Meets EN60335-1
    • Class Ⅰ & Class Ⅱ
    • Short Circuit Protection
    80-264
    130 W
    3.000x2.000x1.20 (Open-frame) 3.598x2.000x1.299 (Baseplate) 3.598x2.520x1.358 (Cover)
  • CFM130M

    CFM130M

    • 2MOOP
    • Altitude 5000m
    • Meets EN60335-1
    • Class I & Class II
    80-264
    130 W
    3.000x2.000x1.20 (Open-frame) 3.598x2.000x1.299 (Baseplate) 3.598x2.520x1.358 (Cover)
  • CFM150S

    CFM150S

    • Universal Input Range 80~264Vac
    • Meets EN60335-1
    • Class Ⅰ & Class Ⅱ
    • High Efficiency up to 94%
    90-264
    150 W
    4.00x2.00x1.283 (Open-frame) 4.598x2.00x1.362 (Baseplate)
  • CFM260S

    CFM260S

    • Universal Input Range 80~264Vac
    • Meets EN60335-1
    • Class I
    • High Efficiency up to 93.5% Typical
    85-264
    260 W
    4.000x2.000x1.441 (Open-frame) 4.598x2.000x1.520 (Baseplate) 4.598x2.520x1.594 (Cover)
  • CFM300M

    CFM300M

    • 2MOOP
    • High Efficiency up to 94%
    • High Power Density up to 14.1W/Inch3
    • Class I
    90-264
    300 W
    5.000x3.000x1.421 (Baseplate) 5.355x3.425x1.591 (Cover)
  • CFM300S

    CFM300S

    • Universal Input Range 80~264Vac
    • Altitude 5000m
    • Meets EN60335-1
    • Class I
    90-264
    300 W
    5.000x3.000x1.421 (Baseplate) 5.355x3.425x1.591 (Cover)
  • CFM500M

    CFM500M

    • 2MOOP
    • Altitude 5000m
    • Meets EN60335-1
    • Class I
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)
  • CFM500S

    CFM500S

    • Universal Input Range 80~264Vac
    • Altitude 5000m
    • Meets EN60335-1
    • High Efficiency up to 94.5%
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)
  • CFM500S-PM

    CFM500S-PM

    • Univerzální vstupní rozsah 80~264V stříd.
    • nadmořská výška 5000 m
    • Splňuje normu EN60335-1
    • Vysoká účinnost až 94,5 %
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)
  • PFC750

    PFC750

    • Low Profile
    • Built-in PFC
    • Altitude 5000
    90-264
    750 W
    2.28x2.40x0.50
  • PDF700S-CMFC(D/D-P)

    PDF700S-CMFC(D/D-P)

    • Univerzální vstupní rozsah 90–264 VAC
    • Účinnost až 91,5 %
    • Bezpečnostní schválení IEC/EN/UL 62368-1 Ed 3.0
    • Provozní výška 5000 m
    90~264Vac
    700 W
    9,45 x 1,65 x 4,33


Description

Datasheet

Input

Power

Size

  • TR15RAM

    TR15RAM

    • 2 MOPP
    • Universal Input Range 90~264Vac
    • High Efficiency up to 82%
    • Class II
    90-264
    15 W
    3.173x1.885x1.704
  • LFM300M-C

    LFM300M-C

    • Univerzální vstupní rozsah 85~264 Vac
    • Vysoká účinnost až 94 %
    • 25,4mm nízkoprofilový balíček
    • Příkon bez zátěže<0,3W
    85~264
    300 W
    4,09 x 1,00 x 2,28
  • TR18RDM

    TR18RDM

    • 2 MOPP
    • Altitude 5000m
    • EN60601-1-11 IP22
    • Meets EN60335-1
    80-264
    18 W
    3.165x1.693x1.453
  • CFM21M

    CFM21M

    • 2MOOP
    • Low Profile
    • Universal Input Range 90~264VAC
    • Altitude 5000m
    90-264
    20 W
    2.38x1.60x0.80 (PCB-mount) 3.00x1.60x0.77 (Wafer) 2.53x1.74x0.80 (Encapsulated) 3.00x1.60x0.77 (Screw Terminal)
  • CFM21

    CFM21

    • 2MOOP
    • Miniature Size Low Profile 0.8”
    • Universal Input Range 90~264VAC
    • IEC/EN/UL 60601-1 Medical Safety Approved
    90-264
    20 W
    2.38x1.60x0.80 (PCB-mount) 3.00x1.60x0.77 (Wafer) 2.53x1.74x0.80 (Encapsulated) 3.00x1.60x0.77 (Screw Terminal)
  • TR30RDM

    TR30RDM

    • 2 MOPP
    • Altitude 5000m
    • EN60601-1-11 IP22
    • Meets EN60335-1
    80-264
    30 W
    3.807x2.283x1.703
  • TR30RAM

    TR30RAM

    • 2 MOPP
    • Universal Input Range 90~264Vac
    • High Efficiency up to 87%
    • Leakage Current < 100uA
    90-264
    30 W
    4.278x2.440x1.445
  • TR36M

    TR36M

    • 2MOPP
    • Altitude 5000m
    • EN60601-1-11 IP21
    • Meets EN60335-1
    80-264
    36 W
    3.937x1.771x0.886
  • CFM40M

    CFM40M

    • 2MOOP
    • Meets EN60335-1
    • Universal Input Range 90~264VAC
    • Medical and ITE Approved
    90-264
    40 W
    3.000x2.000x0.948 (PCB-mount) 3.000x2.000x0.909 (Wafer) 3.200x2.441x1.260 (Cover)
  • TR60M

    TR60M

    • 2MOPP
    • Level V
    • High Efficiency up to 88%
    • Class II
    90-264
    60 W
    5.197x2.283x1.201
  • CFM60M

    CFM60M

    • 2MOOP
    • 2”x 4” Size
    • Universal Input Range 90~264VAC
    • Efficiency to 90%
    90-264
    60 W
    4.000x2.000x1.100 (Wafer) 4.606x2.441x1.575 (Cover)
  • TR70M

    TR70M

    • 2MOPP
    • Altitude 5000m
    • Meets EN60335-1
    80-264
    70 W
    4.724x2.047x1.220
  • TR100M

    TR100M

    • 2MOPP
    • Universal Input Range 90~264Vac
    • High Efficiency up to 98%
    • Class II
    90-264
    100 W
    5.591x2.283x1.457
  • CFM100M

    CFM100M

    • 2MOOP
    • 3”x 5” Compact Size
    • Less than 1 U high
    • High Efficiency up to 92%
    90-264
    100 W
    5.000x3.000x1.050 (Wafer)
  • CFM130M

    CFM130M

    • 2MOOP
    • Altitude 5000m
    • Meets EN60335-1
    • Class I & Class II
    80-264
    130 W
    3.000x2.000x1.20 (Open-frame) 3.598x2.000x1.299 (Baseplate) 3.598x2.520x1.358 (Cover)
  • CFM150M

    CFM150M

    • 2MOOP
    • Universal Input Range 90 ~ 264Vac
    • 3”x 5” Compact Size
    • Less than 1 U High：1.05”
    90-264
    150 W
    5.000x3.000x1.050 (Wafer)
  • TR160M

    TR160M

    • 2MOPP
    • Altitude 5000m
    • Meets EN60335-1
    80-264
    160 W
    5.906x2.756x1.496
  • TR220M

    TR220M

    • 2MOPP
    • Altitude 5000m
    • High Efficiency up to 94%
    • Universal Input Range 80~264Vac
    80-264
    220 W
    7.087x2.953x1.752
  • CFM300M

    CFM300M

    • 2MOOP
    • High Efficiency up to 94%
    • High Power Density up to 14.1W/Inch3
    • Class I
    90-264
    300 W
    5.000x3.000x1.421 (Baseplate) 5.355x3.425x1.591 (Cover)
  • CFM351M

    CFM351M

    • 2MOOP
    • Universal Input Range 90 ~ 264Vac
    • Meets EN60601-1 and EN55011 Class B
    • Active PFC Meets EN61000-3-2 Class D
    90-264
    350 W
    6.500x4.000x1.516 (Wafer)
  • CFM500M

    CFM500M

    • 2MOOP
    • Altitude 5000m
    • Meets EN60335-1
    • Class I
    80-264
    500 W
    5.000x3.000x1.540 (Baseplate) 5.354x3.425x1.673 (Cover)


DC/DC Converters


Description

Datasheet

Input

Power

Size

  • CQB75W14

    CQB75W14

    • 75W izolovaný výstup
    • Účinnost až 91 %
    • Pevná frekvence přepínání
    • Vstupní prostor 14:1
    14:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB50W12

    CQB50W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    50 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB150W12

    CHB150W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    150 Watt
    2.28×2,40x0.50 (Half Brick)
  • CHB200W12

    CHB200W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    200 Watt
    2.28×2,40x0.50 (Half Brick)
  • CHB500W

    CHB500W

    • Účinnost až 91,5 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • Vzdálené zapnutí/vypnutí
    4:1
    500 Watt
    2.28×2,40x0.50 (Half Brick)
  • CEB100W

    CEB100W

    • Účinnost až 93,5 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • 3000Vdc I/O izolace
    4:1
    100 Watt
    2.45”x1.05”x0.5” (Eighth Brick Size)
  • CQB50W8

    CQB50W8

    • 3KVac Isolation
    • UL62368 & CB
    • EN45545-2
    • EN50155 Compliant
    8:1
    50 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB150W14

    CQB150W14

    • Účinnost až 90,5 %
    • Pevná spínací frekvence
    • Vstupní rozsah 14:1
    • Regulované výstupy
    14:1
    150 Watt
    2.28”x1.45”x0.5”
  • CQB75W8

    CQB75W8

    • 3KVac Isolation
    • UL62368 & CB
    • EN45545-2
    • EN50155 Compliant
    8:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB150W8

    CHB150W8

    • 1.5 KVDC Isolation
    • UL60950-1
    • Efficiency to 90%
    • 150W Isolated Output
    8:1
    150 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQB150W14 Series

    CQB150W14 Series

    • Účinnost až 90,5 %
    • Pevná spínací frekvence
    • Vstupní rozsah 14:1
    • Regulované výstupy
    14:1
    150 Watt
    2.28”x1.45”x0.5”
  • CHB50W

    CHB50W

    • 1.5KVDC Isolation
    • UL60950-1
    • 33-50W Isolated Output
    • Efficiency to 87%
    4:1
    50 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQE50W

    CQE50W

    • 1.5KVDC Isolation
    • UL60950-1
    • No Tantalum Capacitor Inside
    • 50W Isolated Output
    4:1
    50 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB60W-110S

    CQB60W-110S

    • 3KVdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    4:1
    60 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB75W

    CHB75W

    • 1.5KVDC Isolation
    • UL60950-1
    • Efficiency to 85%
    • 49.5-75W Isolated Output
    4:1
    75 Watt
    2.28×1.45x0.50 (Half Brick)
  • CQB75W

    CQB75W

    • 1.5KVDC Isolation
    • UL60950-1
    • 39.6-75W Isolated Output
    • Efficiency to 87%
    4:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB100W-110S

    CQB100W-110S

    • 3KVdc Isolation
    • UL60950-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    100 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB100W

    CQB100W

    • 1.5KVDC Isolation
    • UL60950-1
    • 4:1 Input Range
    • Quarter-Brick Package
    4:1
    100 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB100W

    CHB100W

    • 1.5KVDC Isolation
    • UL60950-1
    • 66-100W Isolated Output
    • Half Brick Size
    4:1
    100 Watt
    2.28×2.40x0.50 (Half Brick)
  • CHE100W

    CHE100W

    • 1.5KVDC Isolation
    • 100W Isolated Output
    • 4:1 Input Range
    • High Efficiency to 93%
    4:1
    100 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQB150W-110S

    CQB150W-110S

    • 3KVdc Isolation
    • UL60950-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    150 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB150W

    CQB150W

    • 2250Vdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    150 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB150W

    CHB150W

    • 1.5KVDC Isolation
    • UL60950-1
    • Efficiency to 91%
    • 250KHz Switching Frequency
    4:1
    150 Watt
    2.28×2.40x0.52 (Half Brick)
  • CHB200W-110S

    CHB200W-110S

    • 3KVdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    4:1
    200 Watt
    2.28×2.40x0.50 (Half Brick)
  • CHB200W

    CHB200W

    • 1.5KVDC Isolation
    • UL60950-1
    • Half Brick Size
    • 132-200W Isolated Output
    4:1
    200 Watt
    2.28×2.40x0.52 (Half Brick)
  • CHB300W-110S

    CHB300W-110S

    • 3KVdc Isolation
    • UL60950-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    300 Watt
    2.28×2.40x0.50 (Half Brick)
  • CHB300W

    CHB300W

    • 1.5KVDC Isolation
    • UL62368-1
    • 300W Isolated Output
    • Efficiency to 92%
    4:1
    300 Watt
    2.28×2.40x0.50 (Half Brick)
  • CFB400W

    CFB400W

    • 1.5KVDC Isolation
    • UL60950-1
    • 400W Isolated Output
    • Over Temperature Protection
    4:1
    400 Watt
    4.60×2.40x0.50 (Full Brick)
  • CFB600W-110S

    CFB600W-110S

    • 2250Vdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    4:1
    600 Watt
    4.60×2.40x0.50 (Full Brick)
  • CHB50

    CHB50

    • 1.5KVDC Isolation
    • Half Brick Size
    • Five Sided Shield Metal Case
    • Efficiency to 89%
    2:1
    50 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQB75-300S

    CQB75-300S

    • 3KVAC Isolation
    • UL62368-1 & CB
    2:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB75

    CHB75

    • 1.5KVDC Isolation
    • UL60950-1
    2:1
    75 Watt
    2.28×2.40x0.50 (Half Brick)
  • CHB100

    CHB100

    • 1.5KVDC Isolation
    • UL60950-1
    2:1
    100 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQB100-110S

    CQB100-110S

    • 2250Vdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    2:1
    100 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB100-110S

    CHB100-110S

    • 3KVac Isolation
    • EN45545-2
    • EN50155 Compliant
    2:1
    100 Watt
    2.28×2.40x0.50 (Half Brick)
  • CHB150

    CHB150

    • 1.5KVDC Isolation
    • UL60950-1
    • Efficiency to 89%
    • 99 - 150W Isolated Output
    2:1
    150 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQB150-300S

    CQB150-300S

    • 3KVAC Isolation
    • UL62368-1 & CB
    2:1
    150 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB150-110S

    CHB150-110S

    • 2250Vdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    2:1
    150 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQB200

    CQB200

    • 2250Vdc Isolation
    • UL62368-1
    • EN45545-2
    2:1
    200 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB300-300S

    CHB300-300S

    • 3KVAC Isolation
    • UL60950-1 & CB
    2:1
    300 Watt
    2.28×2.40x0.50 (Half Brick)
  • CHB350

    CHB350

    • 1.5KVDC Isolation
    • Half Brick Size
    • 231-350W Isolated Output
    • Efficiency to 92.5%
    2:1
    350 Watt
    2.28×2.40x0.50 / 2.28×2.40x0.52 (Half Brick)
  • CFB600

    CFB600

    • 1.5KVDC Isolation
    • UL62368-1
    • Efficiency to 88%
    • 00W Isolated Output
    2:1
    600 Watt
    4.60×2.40x0.50 (Full Brick)
  • CFB600-300S

    CFB600-300S

    • 3KVAC Isolation
    • 600W Isolated Output
    • Efficiency to 91%
    • Fixed Switching Frequency
    2:1
    600 Watt
    4.60×2.40x0.50 (Full Brick)
  • CFB750-300S

    CFB750-300S

    • 3KVAC Isolation
    • Efficiency to 91%
    • Fixed Switching Frequency
    • Input Under Voltage Protection
    2:1
    750 Watt
    4.60×2.40x0.50 (Full Brick)
  • CFB800

    CFB800

    • 1.5KVDC Isolation
    • Efficiency Up to 90%
    • Fixed Switching Frequency
    • Regulated Outputs
    2:1
    800 Watt
    4.60×2.40x0.50 (Full Brick)
  • CSC01

    CSC01

    • Aktuální modul sdílení pro Parallel
    • Metody poklesu napětí
    • Žádný požadavek na připojení kolíku pro sdílení
    • Žádný tantalový kondenzátor uvnitř
    11 - 60 Vdc
    -
    1.25X0.80X0.50 Inches


Description

Datasheet

Input

Power

Size

  • EC7AW18-ECRT/EDRT

    EC7AW18-ECRT/EDRT

    • Účinnost až 87 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • Zapnutí/vypnutí dálkového ovládání negativní logiky
    16:1
    10 Watt
    4.00”x2.14”x0.80” Size (ECRT) 4.00”x2.14”x1.38” Size (EDRT)
  • EC7BW18-ECRT/EDRT

    EC7BW18-ECRT/EDRT

    • EN50155/ EN50121-3-2/ EN45545-2
    • Compliant
    • Low Inrush Current
    • Input Reverse Polarity Protection
    16:1
    20 Watt
    4.45x2.33x0.85 (ECRT) 4.45x2.33x1.43 (EDRT)
  • CQB50W12-72SXX-CMFC(D)

    CQB50W12-72SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    12:1
    50 Watt
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CHB200W12-72S-CMFD

    CHB200W12-72S-CMFD

    • Účinnost až 89,5 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • Vzdálené zapnutí/vypnutí
    12:1
    200 Watt
    6.98 x 1.56 x3.09 inches
  • CQB50W8-36SXX-CMFC(D)

    CQB50W8-36SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    8:1
    50 Watt
    4.60x2.40x1.46 (CMFC) 4.60x2.49x1.46 (CMFD)
  • CQB75W8-36SXX-CMFC(D)

    CQB75W8-36SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    8:1
    75 Watt
    4.60x2.40x1.46 (CMFC) 4.60x2.49x1.46 (CMFD)
  • CQB100W-110SXX-CMFC(D)

    CQB100W-110SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    • EN50155 Compliant
    4:1
    100 W
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CQB/CQE50-150W-CM/DIN

    CQB/CQE50-150W-CM/DIN

    • Screw Terminal
    • Chassis Mount/Din Rail Mount
    • 4:1 Wide Input Range
    • 33-150W Isolated Output
    4:1
    100W, 150W, 50W, 75W
    4.41x1.57x1.98
  • CHB/CHE50-100W-CM/DIN

    CHB/CHE50-100W-CM/DIN

    • Screw Terminal
    • 4 : 1 Wide Input Range
    • Regulated Ouputs
    • Input Under Voltage Protection
    4:1
    100W, 50W, 75W
    4.61x2.54x1.03
  • EC5SBW-C(D)MF

    EC5SBW-C(D)MF

    • Účinnost až 90 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • Vzdálené zapnutí/vypnutí
    4:1
    30 W
    3.31x 1.20 x 1.48
  • CQB150W-110SXX-CMFC(D)

    CQB150W-110SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    • EN50155 Compliant
    4:1
    150 W
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CHB200W-110SXX-CMFC(D)

    CHB200W-110SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    • EN50155 Compliant
    4:1
    200 W
    6.50x3.00x1.52 (CMFC) 6.50x3.09x1.57 (CMFD)
  • CHB300W-110SXX-CMFC(D)

    CHB300W-110SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    • EN50155 Compliant
    4:1
    300 W
    6.50x3.00x1.52 (CMFC) 6.50x3.09x1.57 (CMFD)
  • CFB600W-110SXX CMFD

    CFB600W-110SXX CMFD

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    • EN50155 Compliant
    4:1
    600 W
    9.45x4.33x1.65
  • CQB75-300S-CMFC(D)

    CQB75-300S-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    2:1
    75 W
    4.60x2.40x1.24 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CQB150-300SXX CMFC(D)

    CQB150-300SXX CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    2:1
    150 W
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CHB300-300SXX CMFC(D)

    CHB300-300SXX CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    2:1
    300 W
    6.50x3.00x1.52 (CMFC) 6.50x3.09x1.57 (CMFD)
  • CFB750-300SXX-CMFD

    CFB750-300SXX-CMFD

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    2:1
    750 W
    9.45x4.33x1.65


Description

Datasheet

Input

Power

Size

  • CQB75W14

    CQB75W14

    • 75W izolovaný výstup
    • Účinnost až 91 %
    • Pevná frekvence přepínání
    • Vstupní prostor 14:1
    14:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • EC2SBW-H

    EC2SBW-H

    • Účinnost až 89,5 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • Vzdálené zapnutí/vypnutí
    4:1
    10 W
    1.0”x1.0”x0.40”
  • EC1SC

    EC1SC

    • EN55022 Class A
    • 20W Isolated Output
    • Efficiency to 84%
    • 4:1 Input Range
    4:1
    20 W
    2.00×1.60×0.45(DIP)
  • EC7BW18

    EC7BW18

    • 3KVac Isolation
    • UL62368-1
    • EN45545-2
    • EN50155 Compliant
    18:1
    20 W
    2.00x1.00x0.40(DIP)
  • CQB100W14

    CQB100W14

    • 100W izolovaný výstup
    • Účinnost až 90 %
    • Pevná frekvence přepínání
    • Vstupní prostor 14:1
    14:1
    100 W
    2.28”x1.45”x0.5”
  • EC7BW18-ECRT/EDRT

    EC7BW18-ECRT/EDRT

    • EN50155/ EN50121-3-2/ EN45545-2
    • Compliant
    • Low Inrush Current
    • Input Reverse Polarity Protection
    16:1
    20 Watt
    4.45x2.33x0.85 (ECRT) 4.45x2.33x1.43 (EDRT)
  • CQB50W12

    CQB50W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    50 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB50W12-72SXX-CMFC(D)

    CQB50W12-72SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    12:1
    50 Watt
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CHB150W12

    CHB150W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    150 Watt
    2.28×2,40x0.50 (Half Brick)
  • CHB200W12

    CHB200W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    200 Watt
    2.28×2,40x0.50 (Half Brick)
  • CQB50W8-36SXX-CMFC(D)

    CQB50W8-36SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    8:1
    50 Watt
    4.60x2.40x1.46 (CMFC) 4.60x2.49x1.46 (CMFD)
  • CQB50W8

    CQB50W8

    • 3KVac Isolation
    • UL62368 & CB
    • EN45545-2
    • EN50155 Compliant
    8:1
    50 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB75W8-36SXX-CMFC(D)

    CQB75W8-36SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    8:1
    75 Watt
    4.60x2.40x1.46 (CMFC) 4.60x2.49x1.46 (CMFD)
  • CQB75W8

    CQB75W8

    • 3KVac Isolation
    • UL62368 & CB
    • EN45545-2
    • EN50155 Compliant
    8:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB150W8

    CHB150W8

    • 1.5 KVDC Isolation
    • UL60950-1
    • Efficiency to 90%
    • 150W Isolated Output
    8:1
    150 Watt
    2.28×2.40x0.50 (Half Brick)
  • EC3SAWH

    EC3SAWH

    • Efficiency Up to 84.5%
    • Regulated Outputs
    • Positive Remote On/Off
    • 3000Vdc I/O Isolation
    4:1
    3 W
    0.86 [21.8] x 0.44[11.1]
  • EC3SAW

    EC3SAW

    • 1.5KVDC Isolation
    • Input UVP
    4:1
    3 W
    0.86x0.36x0.44(SIP8)
  • EC3AW

    EC3AW

    • 500/1.5K/3KVdc Isolation
    • 3W Isolated Output
    • DIP-24/SMD Package
    • Efficiency to 77%
    4:1
    3 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC4SAWH

    EC4SAWH

    • Efficiency Up to 87.5%
    • Fixed Switching Frequency
    • Regulated Outputs
    • Negative Remote On/Off
    4:1
    6 W
    0.86x0.36x0.44(SIP8)
  • EC4SAW

    EC4SAW

    • 1.5KVDC Isolation
    • 5-6W Isolated Output
    • Compact SIP-8 Package
    • Efficiency up to 89%
    4:1
    6 W
    0.86x0.36x0.44(SIP8)
  • EC4AW

    EC4AW

    • 1.5K/3KVdc Isolation
    • 3.3-6W Isolated Output
    • DIP-24/SMD Package
    • Efficiency to 83%
    4:1
    6 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC6AW

    EC6AW

    • 1.5KVdc Isolation
    • EN50155 Compliant
    4:1
    8 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC7AW

    EC7AW

    • Efficiency up to 89%
    • 4:1 Input Range
    • Fixed Switching Frequency
    • Regulated Outputs
    4:1
    10 W
    1.25”x0.80”x0.40”
  • EC6AW-110

    EC6AW-110

    • 3KVdc Isolation
    • UL60950-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    10 W
    1.25x0.80x0.50(DIP24)
  • EC5SAW

    EC5SAW

    • 3KVDC Isolation
    • 4:1 Input Range
    • Regulated Outputs
    • 3000VDC/2000VAC Isolation
    4:1
    10 W
    0.87x0.37x0.47(SIP8)
  • EC2SBW

    EC2SBW

    • 10W Isolated Output
    • 1.5KVdc Isolation
    • 1”×1”×0.4” Shielded Metal Case
    • Efficiency to 86%
    4:1
    10 W
    1.00x1.00x0.40(DIP)
  • EC5BW

    EC5BW

    • 1.5KVdc Isolation
    • EN55032 Class A
    4:1
    15 W
    2.00x1.00x0.40(DIP)
  • EC3SBW

    EC3SBW

    • 1.5KVdc Isolation
    • 15W Isolated Output
    • 1”x1”x0.4” Shielded Metal Case
    • Efficiency to 88%
    4:1
    15 W
    1.00x1.00x0.40(DIP)
  • EC8AW

    EC8AW

    • 1.5KVdc Isolation
    • EN55032 Class A
    4:1
    15 W
    1.25x0.80x0.40(DIP24)
  • EC7BW

    EC7BW

    • 1.5KVdc Isolation
    • EN45545-2
    • EN50155 Compliant
    4:1
    20 W
    2.00x1.00x0.40(DIP)
  • EC7BW-110

    EC7BW-110

    • 3KVdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    4:1
    20 W
    2.00x1.00x0.40(DIP)
  • EC4SBW

    EC4SBW

    • 1.5KVdc Isolation
    • 20W Isolated Output
    • 1”x1”x0.4” Shielded Metal Case
    • Very High Efficiency Up to 90.5%
    4:1
    20 W
    1.00x1.00x0.40(DIP)
  • EC9BW

    EC9BW

    • 1.5KVdc Isolation
    • 30W Isolated Output
    • Efficiency to 92%
    • 2’’x1’’ Six-Sided Shield Metal Case
    4:1
    30 W
    2.00x1.00x0.40(DIP)
  • EC5SBW

    EC5SBW

    • 1.5KVdc Isolation
    • 30W Isolated Output
    • 1”x1”x0.4” Shielded Metal Case
    • Very High Efficiency Up to 90%
    4:1
    30 W
    1.00x1.00x0.40(DIP)
  • ECLB40W-110

    ECLB40W-110

    • 3KVdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    4:1
    40 W
    2.05x1.20x0.40(DIP)
  • ECLB40W

    ECLB40W

    • 1.5KVdc Isolation
    • With Mounting Inserts
    4:1
    40 W
    2.05x1.20x0.40(DIP)
  • CQE50W

    CQE50W

    • 1.5KVDC Isolation
    • UL60950-1
    • No Tantalum Capacitor Inside
    • 50W Isolated Output
    4:1
    50 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB50W

    CHB50W

    • 1.5KVDC Isolation
    • UL60950-1
    • 33-50W Isolated Output
    • Efficiency to 87%
    4:1
    50 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQB60W-110S

    CQB60W-110S

    • 3KVdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    4:1
    60 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • ECLB60W

    ECLB60W

    • 1.5KVdc Isolation
    • With Mounting Inserts
    4:1
    60 W
    2.05x1.20x0.40(DIP)
  • ECLB75W

    ECLB75W

    • 2.25KVdc Isolation
    • With Mounting Inserts
    4:1
    75 W
    2.05x1.20x0.40(DIP)
  • CQB75W

    CQB75W

    • 1.5KVDC Isolation
    • UL60950-1
    • 39.6-75W Isolated Output
    • Efficiency to 87%
    4:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB75W

    CHB75W

    • 1.5KVDC Isolation
    • UL60950-1
    • Efficiency to 85%
    • 49.5-75W Isolated Output
    4:1
    75 Watt
    2.28×1.45x0.50 (Half Brick)
  • CQB100W-110SXX-CMFC(D)

    CQB100W-110SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    • EN50155 Compliant
    4:1
    100 W
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CQB100W

    CQB100W

    • 1.5KVDC Isolation
    • UL60950-1
    • 4:1 Input Range
    • Quarter-Brick Package
    4:1
    100 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB100W

    CHB100W

    • 1.5KVDC Isolation
    • UL60950-1
    • 66-100W Isolated Output
    • Half Brick Size
    4:1
    100 Watt
    2.28×2.40x0.50 (Half Brick)
  • CQB100W-110S

    CQB100W-110S

    • 3KVdc Isolation
    • UL60950-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    100 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB150W-110S

    CQB150W-110S

    • 3KVdc Isolation
    • UL60950-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    150 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB150W-110SXX-CMFC(D)

    CQB150W-110SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    • EN50155 Compliant
    4:1
    150 W
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CQB150W

    CQB150W

    • 2250Vdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    150 Watt
    2.28×1.45x0.50 (Quarter Brick)


Description

Datasheet

Input

Power

Size

  • CQB75W14

    CQB75W14

    • 75W izolovaný výstup
    • Účinnost až 91 %
    • Pevná frekvence přepínání
    • Vstupní prostor 14:1
    14:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • EC7AW18

    EC7AW18

    • Účinnost až 88 %
    • Pevná frekvence přepínání
    • Regulované výstupy
    • Vzdálené zapnutí/vypnutí
    18:1
    10 W
    1.25”x0.8”x0.5”
  • EC7BW18

    EC7BW18

    • 3KVac Isolation
    • UL62368-1
    • EN45545-2
    • EN50155 Compliant
    18:1
    20 W
    2.00x1.00x0.40(DIP)
  • CQB100W14

    CQB100W14

    • 100W izolovaný výstup
    • Účinnost až 90 %
    • Pevná frekvence přepínání
    • Vstupní prostor 14:1
    14:1
    100 W
    2.28”x1.45”x0.5”
  • EC7BW18-ECRT/EDRT

    EC7BW18-ECRT/EDRT

    • EN50155/ EN50121-3-2/ EN45545-2
    • Compliant
    • Low Inrush Current
    • Input Reverse Polarity Protection
    16:1
    20 Watt
    4.45x2.33x0.85 (ECRT) 4.45x2.33x1.43 (EDRT)
  • CQB50W12

    CQB50W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    50 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB50W12-72SXX-CMFC(D)

    CQB50W12-72SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    12:1
    50 Watt
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • ECB40W18

    ECB40W18

    • Účinnost až 90 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • Vzdálené zapnutí/vypnutí
    18:1
    40 Watt
    2”x1”x0.5” Size
  • CHB150W12

    CHB150W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    150 Watt
    2.28×2,40x0.50 (Half Brick)
  • CHB200W12

    CHB200W12

    • 3KVdc Isolation
    • UL62368-1 & CB
    • EN45545-2
    • EN50155 Compliant
    12:1
    200 Watt
    2.28×2,40x0.50 (Half Brick)
  • CQB50W8-36SXX-CMFC(D)

    CQB50W8-36SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    8:1
    50 Watt
    4.60x2.40x1.46 (CMFC) 4.60x2.49x1.46 (CMFD)
  • CQB50W8

    CQB50W8

    • 3KVac Isolation
    • UL62368 & CB
    • EN45545-2
    • EN50155 Compliant
    8:1
    50 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB75W8-36SXX-CMFC(D)

    CQB75W8-36SXX-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    8:1
    75 Watt
    4.60x2.40x1.46 (CMFC) 4.60x2.49x1.46 (CMFD)
  • CQB75W8

    CQB75W8

    • 3KVac Isolation
    • UL62368 & CB
    • EN45545-2
    • EN50155 Compliant
    8:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CHB150W8

    CHB150W8

    • 1.5 KVDC Isolation
    • UL60950-1
    • Efficiency to 90%
    • 150W Isolated Output
    8:1
    150 Watt
    2.28×2.40x0.50 (Half Brick)
  • EC7AW18 ECRT/EDRT Series

    EC7AW18 ECRT/EDRT Series

    • Účinnost až 87 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • Zapnutí/vypnutí dálkového ovládání negativní logiky
    16:1
    10 Watt
    4.00”x2.14”x0.80”
    Size at ECRT
    4.00”x2.14”x1.38”
    Size at EDRT


Description

Datasheet

Input

Power

Size

  • CQB75-300S

    CQB75-300S

    • 3KVAC Isolation
    • UL62368-1 & CB
    2:1
    75 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB75-300S-CMFC(D)

    CQB75-300S-CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    2:1
    75 W
    4.60x2.40x1.24 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CQB150-300S

    CQB150-300S

    • 3KVAC Isolation
    • UL62368-1 & CB
    2:1
    150 Watt
    2.28×1.45x0.50 (Quarter Brick)
  • CQB150-300SXX CMFC(D)

    CQB150-300SXX CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    2:1
    150 W
    4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)
  • CHB300-300S

    CHB300-300S

    • 3KVAC Isolation
    • UL60950-1 & CB
    2:1
    300 Watt
    2.28×2.40x0.50 (Half Brick)
  • CHB300-300SXX CMFC(D)

    CHB300-300SXX CMFC(D)

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    2:1
    300 W
    6.50x3.00x1.52 (CMFC) 6.50x3.09x1.57 (CMFD)
  • CFB600-300S

    CFB600-300S

    • 3KVAC Isolation
    • 600W Isolated Output
    • Efficiency to 91%
    • Fixed Switching Frequency
    2:1
    600 Watt
    4.60×2.40x0.50 (Full Brick)
  • CFB750-300S

    CFB750-300S

    • 3KVAC Isolation
    • Efficiency to 91%
    • Fixed Switching Frequency
    • Input Under Voltage Protection
    2:1
    750 Watt
    4.60×2.40x0.50 (Full Brick)
  • CFB750-300SXX-CMFD

    CFB750-300SXX-CMFD

    • Screw Terminal
    • Build in filter
    • Baseplate Cooled
    • EN45545-2
    2:1
    750 W
    9.45x4.33x1.65


Description

Datasheet

Input

Power

Size

  • EC4A-E

    EC4A-E

    • 5–6W izolovaný výstup
    • 24kolíkový DIP balíček
    • Účinnost až 87 %
    • Vstupní rozsah 2:1
    2:1
    6 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24) 1.25×0.80x0.41(SMD24)
  • EC1SC

    EC1SC

    • EN55022 Class A
    • 20W Isolated Output
    • Efficiency to 84%
    • 4:1 Input Range
    4:1
    20 W
    2.00×1.60×0.45(DIP)
  • EC4BE

    EC4BE

    • 10W izolovaný výstup
    • 2” x 1” šestistranné štítové kovové pouzdro
    • Účinnost až 82 %
    • Vstupní rozsah 2:1
    2:1
    10 W
    2.00x1.00x0.40(DIP)
  • EC3AW

    EC3AW

    • 500/1.5K/3KVdc Isolation
    • 3W Isolated Output
    • DIP-24/SMD Package
    • Efficiency to 77%
    4:1
    3 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC3AE

    EC3AE

    • 3W izolovaný výstup
    • Balík DIP-24/SMD
    • Účinnost až 61 %
    • Regulované výstupy
    +/-10% Input Range
    3 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC4AW-H6

    EC4AW-H6

    • 5–6W izolovaný výstup
    • Balík DIP-24
    • Regulované výstupy
    • Účinnost až 85 %
    High Isolation 6KV
    6 W
    1.25x0.80x0.40 (DIP24)
  • EC7C

    EC7C

    • 40W izolovaný výstup
    • 2” X 2” šestistranné štítové kovové pouzdro
    • Vysoká účinnost až 93 %
    • Pevná spínací frekvence 350 kHz
    2:1
    40 W
    2.00x2.00x0.40(DIP)
  • EC6C

    EC6C

    • 25–30W izolovaný výstup
    • 2” X 2” šestistranné štítové kovové pouzdro
    • Vstupní rozsah 2:1
    • Regulované výstupy
    2:1
    30 W
    2.00x1.00x0.40(DIP)
  • EC5BE

    EC5BE

    • 15W izolovaný výstup
    • 2” x 1” šestistranné štítové kovové pouzdro
    • Účinnost až 83 %
    • Vstupní rozsah 2:1
    2:1
    15 W
    2.00x1.00x0.40(DIP)
  • EC5BU

    EC5BU

    • 15W izolovaný výstup
    • Účinnost až 90 %
    • Vstupní rozsah 2:1
    • Regulované výstupy
    2:1
    15 W
    2.00x1.00x0.40(DIP)
  • EC3AB

    EC3AB

    • 3W izolovaný výstup
    • Balík DIP-24/SMD
    • Účinnost až 80 %
    • Regulované výstupy
    2:1
    3 W
    1.25x0.80x0.50(DIP24) 1.25x0.80x0.55(SMD24)
  • EC3SAW

    EC3SAW

    • 1.5KVDC Isolation
    • Input UVP
    4:1
    3 W
    0.86x0.36x0.44(SIP8)
  • EC2SA

    EC2SA

    • 2W izolovaný výstup
    • Kompaktní balíček SIP-8
    • Účinnost až 84 %
    • Vstupní rozsah 2:1
    2:1
    2 W
    0.86x0.36x0.44(SIP8)
  • EC4SAWH

    EC4SAWH

    • Efficiency Up to 87.5%
    • Fixed Switching Frequency
    • Regulated Outputs
    • Negative Remote On/Off
    4:1
    6 W
    0.86x0.36x0.44(SIP8)
  • EC4AW

    EC4AW

    • 1.5K/3KVdc Isolation
    • 3.3-6W Isolated Output
    • DIP-24/SMD Package
    • Efficiency to 83%
    4:1
    6 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC4SAW

    EC4SAW

    • 1.5KVDC Isolation
    • 5-6W Isolated Output
    • Compact SIP-8 Package
    • Efficiency up to 89%
    4:1
    6 W
    0.86x0.36x0.44(SIP8)
  • EC4A

    EC4A

    • 5–6W izolovaný výstup
    • 24kolíkový DIP balíček
    • Účinnost až 84 %
    • Vstupní rozsah 2:1
    2:1
    6 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC2SB

    EC2SB

    • 10W izolovaný výstup
    • Účinnost až 87 %
    • Vstupní rozsah 2:1
    • Regulované výstupy
    2:1
    10 W
    1.00x1.00x0.40(DIP) 1.00x1.00x0.36(SMD)
  • EC6A

    EC6A

    • 7,5W izolovaný výstup
    • 24kolíkový DIP balíček
    • Účinnost až 87 %
    • Vstupní rozsah 2:1
    2:1
    7.5 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC4BW

    EC4BW

    • 10W izolovaný výstup
    • Vstupní rozsah 4:1
    • Splňuje EN55022 třída A
    • Filtr vstupu Pi
    4:1
    10 W
    2.00x1.00x0.40(DIP)
  • EC7AW

    EC7AW

    • Efficiency up to 89%
    • 4:1 Input Range
    • Fixed Switching Frequency
    • Regulated Outputs
    4:1
    10 W
    1.25”x0.80”x0.40”
  • EC3SA

    EC3SA

    • 3W izolovaný výstup
    • Kompaktní balíček SIP-8
    • Účinnost až 86 %
    • Vstupní rozsah 2:1
    2:1
    3 W
    0.86x0.36x0.44(SIP8)
  • EC2SBW

    EC2SBW

    • 10W Isolated Output
    • 1.5KVdc Isolation
    • 1”×1”×0.4” Shielded Metal Case
    • Efficiency to 86%
    4:1
    10 W
    1.00x1.00x0.40(DIP)
  • EC5SAW

    EC5SAW

    • 3KVDC Isolation
    • 4:1 Input Range
    • Regulated Outputs
    • 3000VDC/2000VAC Isolation
    4:1
    10 W
    0.87x0.37x0.47(SIP8)
  • EC6AW-110

    EC6AW-110

    • 3KVdc Isolation
    • UL60950-1 & CB
    • EN45545-2
    • EN50155 Compliant
    4:1
    10 W
    1.25x0.80x0.50(DIP24)
  • EC3SB

    EC3SB

    • 15W izolovaný výstup
    • Účinnost až 90 %
    • Vstupní rozsah 2:1
    • Regulované výstupy
    2:1
    15 W
    1.00x1.00x0.40(DIP) 1.00x1.00x0.36(SMD)
  • EC3C

    EC3C

    • 15W izolovaný výstup
    • Účinnost až 82 %
    • 2” x 2” šestistranné štítové kovové pouzdro
    • Alternativní konfigurace pinů
    2:1
    15 W
    2.00x2.00x0.40(DIP)
  • EC7A

    EC7A

    • 10W izolovaný výstup
    • Kovové balení DIP-24/SMD
    • Velmi vysoká účinnost až 89 %
    • Vstupní rozsah 2:1
    2:1
    10 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24)
  • EC5C

    EC5C

    • 15W izolovaný výstup
    • 2” X 2” šestistranné štítové kovové pouzdro
    • Vstupní rozsah 4:1
    • Účinnost až 84 %
    4:1
    15 W
    2.00x2.00x0.40(DIP)
  • EC4BU

    EC4BU

    • 10W izolovaný výstup
    • Účinnost až 87 %
    • Vstupní rozsah 2:1
    • Regulované výstupy
    2:1
    10 W
    2.00x1.00x0.40(DIP)
  • EC5BW

    EC5BW

    • 1.5KVdc Isolation
    • EN55032 Class A
    4:1
    15 W
    2.00x1.00x0.40(DIP)
  • EC8AW

    EC8AW

    • 1.5KVdc Isolation
    • EN55032 Class A
    4:1
    15 W
    1.25x0.80x0.40(DIP24)
  • EC7B

    EC7B

    • 20W izolovaný výstup
    • Účinnost až 90 %
    • Vstupní rozsah 2:1
    • Pevná spínací frekvence
    2:1
    20 W
    2.00x1.00x0.40(DIP)
  • EC3SBW

    EC3SBW

    • 1.5KVdc Isolation
    • 15W Isolated Output
    • 1”x1”x0.4” Shielded Metal Case
    • Efficiency to 88%
    4:1
    15 W
    1.00x1.00x0.40(DIP)
  • EC7BW

    EC7BW

    • 1.5KVdc Isolation
    • EN45545-2
    • EN50155 Compliant
    4:1
    20 W
    2.00x1.00x0.40(DIP)
  • EC3SCW

    EC3SCW

    • 20–30W izolovaný výstup
    • 2” x 1,6” šestistranné štítové kovové pouzdro
    • Vysoká účinnost až 91 %
    • Pevná spínací frekvence 300 kHz
    4:1
    30 W
    2.00×1.60×0.40(DIP)
  • EC4SBW

    EC4SBW

    • 1.5KVdc Isolation
    • 20W Isolated Output
    • 1”x1”x0.4” Shielded Metal Case
    • Very High Efficiency Up to 90.5%
    4:1
    20 W
    1.00x1.00x0.40(DIP)
  • EC7BW-110

    EC7BW-110

    • 3KVdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    4:1
    20 W
    2.00x1.00x0.40(DIP)
  • EC4AB

    EC4AB

    • 5–6W izolovaný výstup
    • Balík DIP-24/SMD
    • Účinnost až 84 %
    • Regulované výstupy
    2:1
    6 W
    1.25x0.80x0.50(DIP24) 1.25x0.80x0.55(SMD24)
  • EC9BW

    EC9BW

    • 1.5KVdc Isolation
    • 30W Isolated Output
    • Efficiency to 92%
    • 2’’x1’’ Six-Sided Shield Metal Case
    4:1
    30 W
    2.00x1.00x0.40(DIP)
  • EC5SBW

    EC5SBW

    • 1.5KVdc Isolation
    • 30W Isolated Output
    • 1”x1”x0.4” Shielded Metal Case
    • Very High Efficiency Up to 90%
    4:1
    30 W
    1.00x1.00x0.40(DIP)
  • ECLB40W

    ECLB40W

    • 1.5KVdc Isolation
    • With Mounting Inserts
    4:1
    40 W
    2.05x1.20x0.40(DIP)
  • ECLB40W-110

    ECLB40W-110

    • 3KVdc Isolation
    • UL60950-1
    • EN45545-2
    • EN50155 Compliant
    4:1
    40 W
    2.05x1.20x0.40(DIP)
  • EC3A-E

    EC3A-E

    • 3W izolovaný výstup
    • 24kolíkový DIP balíček
    • Účinnost až 87 %
    • Vstupní rozsah 2:1
    2:1
    3 W
    1.25x0.80x0.40(DIP24) 1.25×0.80x0.45(SMD24) 1.25×0.80x0.41(SMD24)
  • ECLB60W

    ECLB60W

    • 1.5KVdc Isolation
    • With Mounting Inserts
    4:1
    60 W
    2.05x1.20x0.40(DIP)
  • EC3BB

    EC3BB

    • 7,5W izolovaný výstup
    • Vzdálené zapnutí/vypnutí (volitelné)
    • Účinnost až 82 %
    • Pouzdro 2" x 1"
    2:1
    7.5 W
    2.00x1.00x0.40(DIP)
  • ECLB75W

    ECLB75W

    • 2.25KVdc Isolation
    • With Mounting Inserts
    4:1
    75 W
    2.05x1.20x0.40(DIP)
  • EC5DAW

    EC5DAW

    • Účinnost až 89 %
    • Pevná spínací frekvence
    • Regulované výstupy
    • Negativní dálkové zapínání/vypínání
    4:1
    10 Watt
    0.54 x 0,39 Inch (13.7 x 10 mm)
  • EC3SAWH

    EC3SAWH

    • Účinnost až 84,5 %
    • Regulované výstupy
    • Pozitivní dálkové zapínání/vypínání
    • 3000Vdc I/O izolace
    18~74V, 9~36V
    3 W
    0.86x0.36x0.44(SIP8)


Description

Read more

  • HEATSINK

    HEATSINK

    • Constructed of aluminum AL6063 for optimum heat transfer
    • Designed specifically for DC/DC Converters and other baseplate packages
    • Finished with black anodize plating
    • Mounting hardware and thermal pad are available
  • EMI Filter FM05D

    EMI Filter FM05D

    • Quarter-Brick Size Meet Industrial Standard
    • PCB Mount
    • 5A Filter Module
    • 200VDC Input Voltage Maximum
  • EMI Filter FM10D

    EMI Filter FM10D

    • Half Brick Size Meet Industrial Standard
    • PCB Mount
    • 10A Filter Module
    • 200VDC Input Voltage Maximum
  • EMI Filter FM10/20

    EMI Filter FM10/20

    • Compact Size 2"x1" & 2" x 1.6"
    • PCB Mount
    • 75 VDC Input Voltage (Max)
    • Suitable for Cincon Quarter and Half Bricks
  • EMI Filter FM30R

    EMI Filter FM30R

    • Compact Size 2.28”x1.45”
    • Quarter-Brick Size
    • PCB Mount
    • 30A Filter Module
    • 80VDC Input Voltage Maximum
